Design And Construction Of An LED-Based Reading Lamp
This research delves into the innovative design and construction of an LED-based reading lamp, catering to the growing demand for energy-efficient lighting solutions. Leveraging advanced LED technology, the lamp’s construction focuses on sustainability, durability, and user-centric features. Incorporating ergonomic design principles, the lamp offers adjustable brightness levels and color temperatures to optimize reading conditions and reduce eye strain. The construction process integrates high-quality materials and efficient circuitry to ensure long-term reliability and energy savings. By addressing the need for eco-friendly illumination in contemporary living spaces, this project contributes to the advancement of sustainable lighting solutions while enhancing the reading experience for users.
ABSTRACT
This LED based reading lamp circuit uses ultra-bright white LEDs to provide sufficient light for reading while consuming approximately 3 watts of power. In the case of AC mains failure, the battery backup circuit instantly lights up the LEDs. When the power resumes, the battery supply is automatically disconnected and the lamp circuit again works off AC mains. The power supply circuit consists of 0-7.5V, 500mA step-down transformer X1, rectifier diodes D1 through D4 and filter capacitor C1. Regulator IC 7805 (IC1) provides regulated 5V to LEDs, so there is no variation in the intensity of the lamp light even if the mains power supply fluctuates. A total of ten white LEDs (LED1 through LED10) are connected in parallel across the 5V power supply. Resistors R1 through R10 (each 56 ohms) are connected in series with the white LEDs to limit the current. To increase the intensity of the lamp light, you can add more LEDs in the same manner; a maximum of 15 LEDs can be used for the lamp.
TABLE OF CONTENTS
COVER PAGE
TITLE PAGE
APPROVAL PAGE
DEDICATION
ACKNOWELDGEMENT
ABSTRACT
CHAPTER ONE
1.0 INTRODUCTION
1.1 BACKGROUND OF THE PROJECT
- PURPOSE OF THE PROJECT
- AIM OF THE PROJECT
- OBJECTIVE OF THE PROJECT
- PURPOSE OF THE PROJECT
- LIMITATION OF THE PROJECT
- ADVANTAGES OF THE PROJECT
- PROBLEM OF THE PROJECT
- APPLICATION OF THE PROJECT
- RESEARCH QUESTION
- PROJECT ORGANISATION
CHAPTER TWO
LITERATURE REVIEW
- OVERVIEW OF THE STUDY
- REVIEW OF THE RELATED STUDY
CHAPTER THREE
3.0 CONSTRUCTION METHODOLOGY
3.1 BASIC OF THE SYSTEM
3.2 BLOCK DIAGRAM OF THE SYSTEM
3.3 SYSTEM OPERATION
3.4 CIRCUIT DIAGRAM
3.5 CIRCUIT DESCRIPTION
3.6 DESCRIPTION OF COMPONENTS USED
3.7 POWER SUPPLY UNIT
CHAPTER FOUR
4.0 TESTING AND RESULTS
- CONSTRUCTION PROCEDURE AND TESTING
- INSTALLATION OF THE COMPLET DESIGN
- ASSEMBLING OF SECTIONS
- TESTING OF SYSTEM OPERATION
- COST ANALYSIS
CHAPTER FIVE
- CONCLUSION
- RECOMMENDATION
- REFERENCES
12 watt led bulb circuit diagram, led lamp circuit, 7 watt led bulb circuit, how to make led lamp at home 230v, led lights for home, interesting digital circuits, electronic circuits projects diagrams free, led lights for ceiling
LED based reading lamp
The power supply circuit consists of 0-7.5V, 500mA step-down transformer X1, rectifier diodes D1 through D4 and filter capacitor C1. Regulator IC 7805 (IC1) provides regulated 5V to LEDs, so there is no variation in the intensity of the lamp light even if the mains power supply fluctuates. A total of ten white LEDs (LED1 through LED10) are connected in parallel across the 5V power supply. Resistors R1 through R10 (each 56 ohms) are connected in series with the white LEDs to limit the current. To increase the intensity of the lamp light, you can add more LEDs in the same manner; a maximum of 15 LEDs can be used for the lamp.
LED based reading lamp circuit
When power switch S1 is closed, relay RL1 energises to disconnect the 6V, 4Ah battery (connected across N/C contact of relay RL1) from input to regulator IC1 if battery switch S2 is closed. When power switch S1 is open, relay RL1 de-energises and connects the battery to the input of IC1 via N/C contacts of the relay.
Diodes D5 and D6 are reverse-current protection diodes that don’t allow the battery current to flow towards the power supply section. Diode D7 is for reverse polarity protection of the battery. Before connecting the battery, make sure that it is fully charged.
Construction & testing
The circuit can be assembled on a general-purpose PCB. Arrange all white LEDs (LED1 through LED10) on the PCB. Now remove the bulb holder from the lamp and fix the PCB (where bulb holder was mounted) such that LED light falls on your book properly. No separate reflectors are required for LEDs as the LEDs have inbuilt lens reflectors. Use a heat-sink for IC1 as indicated in the figure.
Caution
Though you can read for hours without eye strain in this lamp light, don’t directly look at white LEDs for long.
